Specification |
|
|
Rated Output |
1.20±0.10 |
|
Nonlinearity |
±0.02%FS |
|
Hysteresis |
±0.02%FS |
|
Repeatability |
±0.01%FS |
|
Creep(30 minutes) |
±0.02%FS/10°C |
|
Zero balance |
±1.00%FS |
|
Temperature effect on zero |
±0.02%FS/10°C |
|
Temperature effect on output |
±0.02%FS/10°C |
|
Input resistance(Ω) |
385±15 |
|
Output resistance(Ω) |
350±5 |
|
Insulation resistance |
≥5000MΩ |
|
Excitation voltage |
10V(DC/AC) |
|
Compensated temperature range |
-10~+50°C |
|
Operating temperature range |
-20~+60°C |
|
Safe overload |
300%FS |
|
Cable |
Φ4X0.5 M(1M) |
|
Cable color code |
Input: red+ black- Output: green+ white- |
